NSD VARILIMIT VS-12PB User Manual

● 10-3 ●
Error
Code
Name Output Status
Detection
timing
Cause Countermeasure
45
INCHING error
Operation
error OFF
At positioning
END
- Inching positioning has ended,
but the machine is not
positioned at the target stop
position.
- The difference between the
current position value prior to
the INCHING operation, and
the target stop position value
was too great.
- Re-designate the target stop
position setting.
46
INCHING
direction input
error
Positioning
STOP
During
positioning
operation
- The INCHING direction was
different from that designated
by the external direction input
(F/R).
- Set external direction input so that
it matches the Initial setting No.42
direction.
Note An error reset is not required.
50
PRE data error
Operation
error OFF
During PRE
operation
- A value designated by the
current position PRE input was
outside the detection range.
- Correct the current position PRE
input value.
- Correct the “scale length” and
“min. current pos. value” settings.
51
No initial setting
System
Ready OFF
In RUN and
TEST modes
- Initial setting and/or parameter
setting has not been designated.
- designate the Initial settings.
52
Operation
selection input
error
System
Ready OFF
In RUN mode
- Both the OPE1 and OPE2
operation selection signals
(external inputs) are OFF.
- Correct the operation selection
input.
Note
An error reset is not required.
60
Parameter data
error
System
Ready OFF
At power ON,
program
changes
- Parameter setting data is
incorrect.
- Correct the parameter setting
data.
- Check all the data.
61
Program No.1
data error
System
Ready OFF
At power ON,
program
changes
- Program No.1 setting data is
incorrect.
- Correct the Program No.1 setting
data.
69
Current pos.
data error
System
Ready OFF
At power ON
- One of the following setting is
Incorrect: Currentpos.value,
FWD STOP zone, RVS STOP
zone, brake count, target stop
position.
- Check the settings, and
re-designate the error data.
70
Data reading
error
System
Ready OFF
At internal data
change
- Data has not been written
correctly.
- Re-designate the setting data.
80
External output
error
System
Ready OFF
In RUN and
TEST modes.
- An output malfunction at one of
the following: forward (FWD),
reverse (RVS), operation error
(ERR), System Ready (READY).
- External 24V power supply is
disconnected.
- Check 4 output signals of the
external line shown in left column.
- VS-12PB has a malfunction.
Contact your NSD representative.
10-2. Error Reset Procedure
After the error cause has been corrected (see section 10-1 Table), reset the error status by one of the following
methods.
Reset method 1 Switch the external reset input ON.
Reset method 2
Press the key at the control panel.
