NSD VARILIMIT VS-12PB User Manual

● APPX-5 ●
Parameter
No.
Item Description Setting Data
Setting
value
69
Off-line output status
selection
Designates the switch output status when the
RUN mode is off-line.
All points OFF :
HOLD :
0
1
70
Current position PRE
function selection
Determines whether or not the “current position preset”
and “machine position confirmation” functions are to be
used. The “machine position confirmation” function uses
preset input 2 as the machine position confirmation
input. Preset input 1 is used as the “current position
preset” function.
None :
Current position PRE function :
Machine position check :
0
1
2
71
CW Current
pos.PRE1
Designates the preset value for input 1 during
CW travel (current position preset value).
Setting range
[Min.current pos. value to (Min.
current pos. value + scale
length-1)]
0
72
CCW Current
pos.PRE1
Designates the preset value for input 1 during
CCW travel
0
73
CW Current
pos.PRE2
Designates the preset value for input 2 during
CW travel
0
74
CCW Current
pos. PRE2
Designates the preset value for input 2 during
CCW travel
0
75
Current pos.output
time
Designate the current pos. output and latch pulse
timing.
[time setting] n × 4 ms
n =1 ~ 64
Note
A setting of “0” should be designated if the current
pos. output is to be updated by a DTC input.
Refer to section 8-1-3 for details regarding the
DTC input
Setting range: [0 ~ 64]
1
