106
Other Functions (TC4 and TC2) Section 4-7
!Caution If the MV is stored or calculated at the G3ZA and the G3ZA is turned ON
before the EJ1, the controlled variable produced at the G3ZA will be output
(the output may not be 0.0%) until the EJ1 starts operating. When using MV
storage or MV calculation, verify that the controlled variable produced by the
G3ZA is appropriate.
■ Example
In this example, the TC4's channel 1 Control output (heating) is output to
G3ZA channels 1 to 4.
Channel 1 MV
Channel 2 MV
Channel 3 MV
Channel 4 MV
TC4 G3ZA
Operation
Operation
Operation
Operation
Channel 1 controlled variable
Channel 2 controlled variable
Channel 3 controlled variable
Channel 4 controlled variable
Set with the Source
Channel parameter.
Set with the Slope and
Offset parameters.
CH1 Control Output (Heating)
CH2 Control Output (Heating)
CH3 Control Output (Heating)
CH4 Control Output (Heating)
G3ZA settings Set value
CH1 Source Channel 1
CH2 Source Channel 1
CH3 Source Channel 1
CH4 Source Channel 1
To Next Page
