Omron EJ1 User Manual

105
Other Functions (TC4 and TC2) Section 4-7
Sending MVs to the
G3ZA
The G3ZA's unit number and model determine which MVs are sent from the
EJ1 to the G3ZA.
G3ZA Models with 4
Channels
The EJ1 uses the G3ZA's unit number to determine whether to send heating
outputs or cooling outputs.
Note With a TC2, the Channel 3 and 4 MVs will be set to 0.0%.
G3ZA Models with 8
Channels
The following outputs will be sent whether the control method is set to stan-
dard or heating/cooling control.
Note (1) When standard control is being used, the Channel 5 to 8 MVs will be set
to 0.0%.
(2) With a TC2, the Channel 3, 4, 7, and 8 MVs will be set to 0.0%.
MVs Output from the
G3ZA
The outputs of predetermined channels are set in the G3ZA's MV, but any MV
can be output to multiple channels by setting the G3ZA's “Source Channel.”
Arithmetic operations can also be executed on each MV.
TC4 EDU Host device
G3ZA G3ZA
Unit No. 1
Unit No. 0 Unit No. 1
[STX]0100001029A0219000001000A[ETX][BCC]
Send the following command from the host device
to TC4 when setting the Channel 2 Heater
Burnout Detection Value to 10 A in the G3ZA with
unit number 1.
Channel 1 MV
Channel 2 MV
Channel 3 MV
Channel 4 MV
TC4 G3ZA
CH1 Control Output (Heating)
CH2 Control Output (Heating)
CH3 Control Output (Heating)
CH4 Control Output (Heating)
Channel 1 MV
Channel 2 MV
Channel 3 MV
Channel 4 MV
TC4 G3ZA
CH1 Control Output (Cooling)
CH2 Control Output (Cooling)
CH3 Control Output (Cooling)
CH4 Control Output (Cooling)
• G3ZA Units with unit numbers 0 to 7 • G3ZA Units with unit numbers 8 to 15
Channel 1 MV
Channel 2 MV
Channel 3 MV
Channel 4 MV
Channel 5 MV
Channel 6 MV
Channel 7 MV
Channel 8 MV
TC4 G3ZA
CH1 Control Output (Heating)
CH2 Control Output (Heating)
CH3 Control Output (Heating)
CH4 Control Output (Heating)
CH1 Control Output (Cooling)
CH2 Control Output (Cooling)
CH3 Control Output (Cooling)
CH4 Control Output (Cooling)
