Programless Communications Section 5-1
• Multi Action
Operation of writing any parameters in the download area settings that
have changed from the previous values is performed continuously.
• Stop Operation
Operation is stopped after a series of operations has been completed.
Note (1) Always set the Setting Change Request Bits last. If the Setting
Change Request Bits are set before the set value is changed, an
unexpected value will be written.
(2) All programless download parameters will be updated when the
Setting Change Request Bits are set. If set values are not the
same in EJ1 and PLC memory, e.g., when the power is turned ON
or the bank is changed, always change the values in PLC memo-
ry first and then set the Setting Change Request Bits.
Upload Area Download Area
Value
0002
Operation Command
Response
Bits
Address ValueAddress
m+0
m+1
m+2
m+4
···
n+0
n+1
n+2
n+4
Operation Command
Request Bits
YYYY
Monitor value
Communications
Status
m+3 n+3
Operation
Command Code
Read Response
Bits
Read Request Bits
0002
PLC EJ1
HFU TC4/2
YYYY YYYY
1. The Setting Change Request
Bits are set by the PLC.
2. The EJ1 sets the Setting
Change Response Bits.
3. The EJ1 repeatedly
reads the set values.
Upload Area Download Area
Value
0000
Operation Command
Response Bits
Address ValueAddress
m+0
m+1
m+2
m+4
···
n+0
n+1
n+2
n+4
Operation Command
Request Bits
YYYYMonitor value
Communications
Status
m+3 n+3
Operation
Command Code
Read Response
Bits
Read Request Bits
0000
PLC
2. The EJ1 clears the Setting
Change Response Bits.
1. The Setting Change Request
Bits are cleared by the PLC.
