Programless Communications Section 5-1
■ Set Values
• If the set value contains a decimal point, omit the decimal point and set
the value.
Example:100.0
→ 1000 or 03E8H: set value
• When changing set values, always set a new value within the setting
range. The set value will not be changed if a value outside the range is
set.
Operation Commands When the EJ1 confirms that the Operation Command Request Bits have been
set by the PLC, the EJ1 reads the operation command code set in PLC mem-
ory and accepts the operation command.
To execute an operation command, set the operation command code in the
PLC memory words corresponding to the Programless Download Settings
and then set the Operation Command Request Bits.
Note Refer to 5-1-5 Operation Command Codes for Programless Com-
munications for information on operation command codes.
• Single Operation Command
Operation commands are accepted only once.
Upload Area Download Area
Memory
0001
Setting Change
Response Bits
Address MemoryAddress
m+0
m+1
m+2
m+4
···
n+0
n+1
n+2
n+4
Setting Change
Request Bits
Set valueMonitor value
Communications
Status
m+3 n+3
zzzz
Read Response
Bits
Read Request Bits
0001
Upload Area Download Area
Memory
0000
Setting Change
Response Bits
Address MemoryAddress
m+0
m+1
m+2
m+4
n+0
n+1
n+2
n+4
Setting Change
Request Bits
Set valueMonitor value
Communications
Status
m+3 n+3
zzzz
Read Response
Bits
Read Request Bits
0000
PLC
PLC
EJ1
HFU TC4/2
zzzz zzzz
1. The Operation Command Code
is changed by the PLC.
3. The EJ1 reads the operation
command code.
4. The EJ1 sets the Operation
Command Response Bits.
2. The Operation Command
Request Bits are set by the PLC.
5. The Operation Command Request
Bits are cleared by the PLC.
6. The EJ1 clears the Operation
Command Response Bits.
