Parameter List Appendix
Note Valid after a Software Reset operation command or after power is turned ON. Refer to the G3ZA Multi-
channel Power Controller User’s Manual (Cat. No. Z200).
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
DA (9A) Can be
changed
during
operation.
0100 G3ZA1 - CH1 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0101 G3ZA1 - CH2 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0102 G3ZA1 - CH3 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0103 G3ZA1 - CH4 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0104 G3ZA1 - CH5 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0105 G3ZA1 - CH6 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0106 G3ZA1 - CH7 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0107 G3ZA1 - CH8 Slope H' 00000000 to H' 00000FA0 (0.0 to 400.0) 100.0 % NUM ● ---
0108 G3ZA1 - CH1 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
0109 G3ZA1 - CH2 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010A G3ZA1 - CH3 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010B G3ZA1 - CH4 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010C G3ZA1 - CH5 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010D G3ZA1 - CH6 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010E G3ZA1 - CH7 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
010F G3ZA1 - CH8 Offset H' FFFFF060 to H' 00000FA0 (−400.0 to 400.0) 0.0 % NUM ● ---
0110 G3ZA1 - CH1 Source Channel H' 00000001 to H' 00000008 (1 to 8) 1 --- NUM ● ---
0111 G3ZA1 - CH2 Source Channel H' 00000001 to H' 00000008 (1 to 8) 2 --- NUM ● ---
0112 G3ZA1 - CH3 Source Channel H' 00000001 to H' 00000008 (1 to 8) 3 --- NUM ● ---
0113 G3ZA1 - CH4 Source Channel H' 00000001 to H' 00000008 (1 to 8) 4 --- NUM ● ---
0114 G3ZA1 - CH5 Source Channel H' 00000001 to H' 00000008 (1 to 8) 5 --- NUM ● ---
0115 G3ZA1 - CH6 Source Channel H' 00000001 to H' 00000008 (1 to 8) 6 --- NUM ● ---
0116 G3ZA1 - CH7 Source Channel H' 00000001 to H' 00000008 (1 to 8) 7 --- NUM ● ---
0117 G3ZA1 - CH8 Source Channel H' 00000001 to H' 00000008 (1 to 8) 8 --- NUM ● ---
0118 G3ZA1 - CH1 Heater Burnout Detection Value H' 00000000 to H' 00000032 (0 to 50) 0 A NUM ● ---
0119 G3ZA1 - CH2 Heater Burnout Detection Value H' 00000000 to H' 00000032 (0 to 50) 0 A NUM ● ---
011A G3ZA1 - CH3 Heater Burnout Detection Value H' 00000000 to H' 00000032 (0 to 50) 0 A NUM ● ---
011B G3ZA1 - CH4 Heater Burnout Detection Value H' 00000000 to H' 00000032 (0 to 50) 0 A NUM ● ---
011C G3ZA1 - CH1 SSR Short-circuit Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
011D G3ZA1 - CH2 SSR Short-circuit Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
011E G3ZA1 - CH3 SSR Short-circuit Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
011F G3ZA1 - CH4 SSR Short-circuit Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
0120 G3ZA1 - CH1 Heater Overcurrent Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
0121 G3ZA1 - CH2 Heater Overcurrent Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
0122 G3ZA1 - CH3 Heater Overcurrent Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
0123 G3ZA1 - CH4 Heater Overcurrent Detection
Value
H' 00000000 to H' 00000032 (0 to 50) 50 A NUM ● ---
0124 G3ZA1 - Offset Control H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
1 --- NUM ● ---
0180 G3ZA1 - Send Standby Time (See note.) H' 00000000 to H' 00000063 (0 to 99) 20 ms NUM ● ---
0181 G3ZA1 - Communications Timeout Time H' 00000000 to H' 0000003C (0 to 60)
(Function stops when set to 0.)
0 min NUM ● ---
0182 G3ZA1 - Setting Operation for Errors (See
note.)
H' 00000000: Continue with error clear (0)
H' 00000001: Continue without error clear (1)
H' 00000002: Stop (2)
0 --- NUM ● ---
0183 G3ZA1 - Offset Value H' 00000000 to H' 000003E8 (0.0 to 100.0) 20.0 % NUM ● ---
0184 G3ZA1 - Hysteresis H' 00000001 to H' 0000000A (1 to 10) 1 A NUM ● ---
Not used.
0200 G3ZA2 - CH1 Slope The rest are the same as the G3ZA1.
···
···
0300 G3ZA3 - CH1 Slope
···
···
0400 G3ZA4 - CH1 Slope
···
···
0500 G3ZA5 - CH1 Slope
···
···
0600 G3ZA6 - CH1 Slope
···
···
0700 G3ZA7 - CH1 Slope
···
···
0800 G3ZA8 - CH1 Slope
···
···
