Omron EJ1

202
Parameter List Appendix
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
E0 (A0) Can be
changed
while
stopped.
Not used.
0001 Cold Junction Compensation Method H' 00000000: Externally (0)
H' 00000001: Internally (1)
1 --- Common ● ---
0100 Input Type - CH1 H' 00000000: Pt100 (0)
H' 00000001: Pt100 (1)
H' 00000002: Pt100 (2)
H' 00000003: JPt100 (3)
H' 00000004: JPt100 (4)
H' 00000005: K (5)
H' 00000006: K (6)
H' 00000007: J (7)
H' 00000008: J (8)
H' 00000009: T (9)
H' 0000000A: T (10)
H' 0000000B: E (11)
H' 0000000C: L (12)
H' 0000000D: U (13)
H' 0000000E: U (14)
H' 0000000F: N (15)
H' 00000010: R (16)
H' 00000011: S (17)
H' 00000012: B (18)
H' 00000013: W (19)
H' 00000014: PLII (20)
H' 00000015: 10 to 70°C (21)
H' 00000016: 60 to 120°C (22)
H' 00000017: 115 to 165°C (23)
H' 00000018: 140 to 260°C (24)
H' 00000019: 4 to 20 mA (25)
H' 0000001A: 0 to 20 mA (26)
H' 0000001B: 1 to 5 V (27)
H' 0000001C: 0 to 5 V (28)
H' 0000001D: 0 to 10 V (29)
5--- ch ● ---
0101 Temperature Unit - CH1 H' 00000000: °C (0)
H' 00000001: °F (1)
0--- ch ● ---
0102 Scaling Upper Limit - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) 1000 --- ch ● ---
0103 Scaling Lower Limit - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) 0 --- ch ● ---
0104 Decimal Point Position - CH1 H' 00000000: **** (No decimal point) (0)
H' 00000001: ***.* (1)
H' 00000002: **.** (2)
H' 00000003: *.*** (3)
1--- ch ● ---
Not used.
0200 Input Type - CH2 The rest are the same as channel 1.
··· ···
0300 Input Type - CH3 TC4 ---
··· ···
0400 Input Type - CH4 TC4 ---
··· ···
