203
Parameter List Appendix
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
E1 (A1) Can be
changed
while
stopped.
0100 Control Output 1 Assignment H' 00000000: Disabled (0)
H' 00000001: Temperature Controller error (1)
47 --- IO ● ---
H' 00000002: All channels All alarm OR (2)
H' 00000003: All channels All alarm AND (3)
H' 00000004: All channels Alarm 1 OR (4)
H' 00000005: All channels Alarm 2 OR (5)
H' 00000006: All channels Alarm 3 OR (6)
H' 00000007: All channels Alarm 1 AND (7)
H' 00000008: All channels Alarm 2 AND (8)
H' 00000009: All channels Alarm 3 AND (9)
H' 0000000A: All channels Input error OR (10)
H' 0000000B: All channels RSP Input error OR (11)
●
Not used.
H' 0000000D: All channels HB alarm OR (13)
H' 0000000E: All channels HS alarm OR (14)
H' 0000000F: All channels OC alarm OR (15)
Not used.
H' 00000020: CH1 Alarm 1 (32)
H' 00000021: CH1 Alarm 2 (33)
H' 00000022: CH1 Alarm 3 (34)
H' 00000023: CH1 All alarm OR (35)
H' 00000024: CH1 All alarm AND (36)
H' 00000025: CH1 Input error (37)
H' 00000026: CH1 RSP Input error (38)
Not used.
H' 00000028: CH1 HB alarm (40)
H' 00000029: CH1 HS alarm (41)
H' 0000002A: CH1 OC alarm (42)
H' 0000002B: CH1 PV (43)
H' 0000002C: CH1 SP (44)
H' 0000002D: CH1 Local SP (45)
H' 0000002E: CH1 Remote SP (46)
H' 0000002F: CH1 Control output (heating) (47)
H' 00000030: CH1 Control output (cooling) (48)
Not used.
H' 00000040: Channel 2: The same as channel 1. (64)
···
H' 00000060: Channel 3: The same as channel 1. (96) TC4
···
H' 00000080: Channel 4: The same as channel 1. (128)
···
0101 Control Period 1 H' 00000000 to H' 00000063 (0 to 99)
(0.5 s period when set to 0.)
2sIO● ---
Not used.
0103 Output Scaling Upper Limit 1 H' FFFFF831 to H' 0000270F (−1999 to 9999) 100 --- IO ● ---
0104 Output Scaling Lower Limit 1 H' FFFFF831 to H' 0000270F (−1999 to 9999) 0 --- IO ● ---
0105 Decimal Point C1 H' 00000000: **** (No decimal point) (0)
H' 00000001: ***.* (1)
H' 00000002: **.** (2)
H' 00000003: *.*** (3)
0---IO ● ---
Not used.
0200 Control Output 2 Assignment The rest are the same as from Control Output 1
Assignment to Decimal Point C1.
TC4: 79
TC2: 79
···
···
0300 Control Output 3 Assignment
TC4: 111
TC2: 32
···
···
0400 Control Output 4 Assignment
TC4: 143
TC2: 64
···
···
