Omron EJ1

204
Parameter List Appendix
Note The decimal point position is determined by the sensor selection. With analog inputs, the decimal point
position is determined by the Decimal Point Position parameter setting. In this case, however, the 0 (****)
decimal point position setting will be treated as a setting of 1 (***.*).
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
E3 (A3) Can be
changed
while
stopped.
Not used.
0100 Alarm 1 Type - CH1 H' 00000000: Alarm function OFF (0)
H' 00000001: Upper and lower limit alarm (1)
H' 00000002: Upper limit alarm (2)
H' 00000003: Lower limit alarm (3)
H' 00000004: Upper and lower limit range alarm (4)
H' 00000005: Upper and lower limit alarm with standby
sequence (5)
H' 00000006: Upper limit alarm with standby sequence
(6)
H' 00000007: Lower limit alarm with standby sequence
(7)
H' 00000008: Absolute value upper limit alarm (8)
H' 00000009: Absolute value lower limit alarm (9)
H' 0000000A: Absolute value upper limit alarm with
standby sequence (10)
H' 0000000B: Absolute value lower limit alarm with
standby sequence (11)
H' 0000000C: LBA (Loop Burnout Alarm) (12)
2--- ch ● ---
0101 Alarm 1 Latch - CH1 H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0--- ch ● ---
0102 Alarm 1 Hysteresis - CH1 H' 00000001 to H' 0000270F (1 to 9999) 2 EU (See
note.)
ch ● ---
0103 Alarm 1 Open in Alarm - CH1 H' 00000000: Close in alarm (0)
H' 00000001: Open in alarm (1)
0--- ch ● ---
0104 Alarm 1 ON Delay - CH1 H' 00000000 to H' 000003E7 (0 to 999) 0 Seconds ch ● ---
0105 Alarm 1 OFF Delay - CH1 H' 00000000 to H' 000003E7 (0 to 999) 0 Seconds ch ● ---
0106 Alarm 1 SP Selection - CH1 H' 00000000: Ramp SP (0)
H' 00000001: Target SP (1)
0--- ch ● ---
0107 Alarm 2 Type - CH1 The rest are the same as Alarm 1.
··· ···
010E Alarm 3 Type - CH1
··· ···
0115 LBA Detection Time - CH1 H' 00000000 to H' 0000270F (0 to 9999) 0 Seconds ch ● ---
0116 LBA Level - CH1 H' 00000001 to H' 0000270F (1 to 9999) 80 EU (See
note.)
ch ● ---
0117 LBA Band - CH1 H' 00000000 to H' 0000270F (0 to 9999) 30 EU (See
note.)
ch ● ---
Not used.
0200 Alarm 1 Type - CH2 The rest are the same as channel 1.
··· ···
0300 Alarm 1 Type - CH3 TC4 ---
··· ···
0400 Alarm 1 Type - CH4 TC4 ---
··· ···
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
E4 (A4) Can be
changed
while
stopped.
0100 CT1 Assignment H' 00000000: Disabled (0)
H' 00000001: Control output 1 (1)
H' 00000002: Control output 2 (2)
H' 00000003: Control output 3 (3)
H' 00000004: Control output 4 (4)
1 --- IO TC2 ---
0101 Heater Burnout 1 Latch H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0 --- IO TC2 ---
0102 Heater Burnout 1 Hysteresis H' 00000001 to H' 000003E8 (0.1 to 100.0) 0.1 A IO TC2 ---
0103 HS Alarm 1 Latch H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0 --- IO TC2 ---
0104 HS Alarm 1 Hysteresis H' 00000001 to H' 000003E8 (0.1 to 100.0) 0.1 A IO TC2 ---
0105 Heater Overcurrent 1 Latch H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0 --- IO TC2 ---
0106 Heater Overcurrent 1 Hysteresis H' 00000001 to H' 000003E8 (0.1 to 100.0) 0.1 A IO TC2 ---
Not used.
0200 CT2 Assignment The rest are the same as from CT1 Assignment to
Heater Overcurrent 1 Hysteresis.
