Omron EJ1

205
Parameter List Appendix
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
E5 (A5) Can be
changed
while
stopped.
0000 AT Calculated Gain H' 00000001 to H' 00000064 (0.1 to 10.0) 0.8 --- Common ● ---
0001 Limit Cycle MV Amplitude H' 00000032 to H' 000001F4 (5.0 to 50.0) 20.0 % Common ● ---
0002 Disturbance Overshoot Adjustment Function H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0 --- Common ● ---
Not used.
0100 Direct/Reverse Operation - CH1 H' 00000000: Reverse operation (0)
H' 00000001: Direct operation (1)
0--- ch ● ---
0101 SP Ramp Time Unit - CH1 H' 00000000: Seconds (0)
H' 00000001: Minutes (1)
1--- ch ● ---
0102 AT Hysteresis - CH1 H' 00000001 to H' 0000270F (1 to 9999) 8 EU (See
note.)
ch ● ---
0103 Temporary AT Execution Judgement Deviation
- CH1
H' 00000000 to H' 0000270F (0 to 9999) 1500 EU (See
note.)
ch ● ---
Not used.
0105 RT - CH1 H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0--- ch ● ---
0106 PID/OnOff - CH1 H' 00000000: 2-PID control (0)
H' 00000001: ON-OFF control (1)
0--- ch ● ---
0107 Output Mode Selection - CH1 H' 00000000: Standard control (0)
H' 00000001: Heating/cooling control(1)
0--- ch ● ---
0108 SP Tracking - CH1 H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0--- ch ● ---
Not used.
0200 Direct/Reverse Operation - CH2 The rest are the same as channel 1.
··· ···
Note: The SP Tracking - CH2 parameter is supported only by the TC4.
0300 Direct/Reverse Operation - CH3 Note: The SP Tracking - CH3 parameter cannot be used. TC4 ---
··· ···
0400 Direct/Reverse Operation - CH4 Note: The SP Tracking - CH4 parameter cannot be used. TC4 ---
··· ···
