Parameter List Appendix
Note (1) Not valid when an NT Link is being used.
(2) Set the Delay between Outputs parameter to an even number. If an odd number is set, the next
smaller even number will be used.
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
F0 (B0) Enabled
after
resetting.
0000 Remote SP Enable
H' 00000000:
Disabled (0)
H' 00000001:
Enabled (1)
0---
Common ●
---
0001 Operation After Power ON H' 00000000: Continue (0)
H' 00000001: Stop (1)
H' 00000002: Manual mode (2)
0---
Common ●
---
Not used.
0003 Operation During Error (Selection B) H' 00000000: Notification only (Continue) (0)
H' 00000001: MV at PV error (1)
H' 00000002: Control Stop (2)
0---
Common ●
---
Not used.
0021 Port B Communications Baud Rate (TC4/TC2) Not used. 3--- Common ●●
H' 00000003: 9.6 (3)
H' 00000004: 19.2 (4)
H' 00000005: 38.4 (5)
H' 00000006: 57.6 (6)
H' 00000007: 115.2 (7) (kbps)
Port C Communications Baud Rate (HFU) 7
0022 Port B Communications Data Length (TC4/TC2) H' 00000000: 7 (0)
H' 00000001: 8 (1) (bit)
0---
Common ●●
Port C Communications Data Length (HFU) 1
0023 Port B Communications Parity (TC4/TC2) H' 00000000: None (0)
H' 00000001: Even (1)
H' 00000002: Odd (2)
1---
Common ●●
Port C Communications Parity (HFU) 1
0024 Port B Communications Stop Bits (TC4/TC2) H' 00000000: 1 (0)
H' 00000001: 2 (1) (bit)
1---
Common ●●
Port C Communications Stop Bits (HFU) 0
0025 Port B Send Wait Time (TC4/TC2) H' 00000001 to H' 00000063 (1 to 99) 5 ms
Common ●●
Port C Send Wait Time (HFU) 5
0026 Port A Communications Send Wait Time H' 00000001 to H' 00000063 (1 to 99) 1 ms
Common ●●
Not used.
0029 Proportional Band x10 Compensation H' 00000000: Disabled (0)
H' 00000001: Enabled (1)
0---
Common ●
---
0030 Programless Communications Protocol
Not used. 2--- Common --- ●
H' 00000002: NT Link (1:N) (2)
Not used.
H' 00000005: MC protocol (format 5) (5)
0031 Programless Communications Upload Data
Area
NT Link (1:N)
H' 00000000: DM (0)
H' 00000001: EM0 (1)
H' 00000002: EM1 (2)
H' 00000003: EM2 (3)
H' 00000004: EM3 (4)
H' 00000005: EM4 (5)
H' 00000006: EM5 (6)
H' 00000007: EM6 (7)
H' 00000008: EM7 (8)
H' 00000009: EM8 (9)
H' 0000000A: EM9 (10)
H' 0000000B: EMA (11)
H' 0000000C: EMB (12)
H' 0000000D: EMC (13)
0---
Common --- ●
MC protocol (format 5) H' 00000000: Data register (D) (0)
H' 00000001: Link register (W) (1)
H' 00000002: File register (R) (2)
0
0032 Programless Communications Download Data
Area
NT Link (1:N)
H' 00000000: DM (0)
H' 00000001: EM0 (1)
H' 00000002: EM1 (2)
H' 00000003: EM2 (3)
H' 00000004: EM3 (4)
H' 00000005: EM4 (5)
H' 00000006: EM5 (6)
H' 00000007: EM6 (7)
H' 00000008: EM7 (8)
H' 00000009: EM8 (9)
H' 0000000A: EM9 (10)
H' 0000000B: EMA (11)
H' 0000000C: EMB (12)
H' 0000000D: EMC (13)
0---
Common --- ●
MC protocol (format 5) H' 00000000: Data register (D) (0)
H' 00000001: Link register (W) (1)
H' 00000002: File register (R) (2)
0
0033 Programless Communications Upload Start
Address
H' 00000000 to H' 00007FFF (0 to 32767) 0 ---
Common
---
●
0034 Programless Communications Download Start
Address
H' 00000000 to H' 00007FFF (0 to 32767) 500 ---
Common
---
●
0035 Programless Communications Receive Wait
Time (See note 1.)
H' 0000000A to H' 00002710 (10 to 10000) 2000 ms
Common
---
●
0036 Programless Communications Node Address
(See note 1.)
H' 00000000 to H' 00000063 (0 to 99) 0 --- Common --- ●
0040 Output ON Scheduling Method H' 00000000: No control (0)
H' 00000001: 1/2 (1)
0---
Common ●
---
H' 00000002: 1/4 (2) TC4 ---
Not used.
0042 Delay Between Output Channels (See note 2.) H' 00000000 to H' 000003E8 (0 to 1000) 10 ms
Common ●
---
