Parameter List Appendix
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
F2 (B2)
Enabled
after
resetting.
0000 Event Input 1 Assignment H' 00000000: Disabled (0)
H' 00000001: All channels Bank (bit0) (1)
H' 00000002: All channels Bank (bit1) (2)
H' 00000003: All channels Stop (0)/Run (1) (3)
H' 00000004: All channels Run (0)/Stop (1) (4)
H' 00000005: All channels Auto (0)/Manual (1) (5)
H' 00000006: All channels SP mode (Local (0)/Remote
(1)) (6)
0 --- Common TC2 ---
Not used.
H' 00000020: CH1 Bank (bit0) (32)
H' 00000021: CH1 Bank (bit1) (33)
H' 00000022: CH1 Stop (0)/Run (1) (34)
H' 00000023: CH1 Run (0)/Stop (1) (35)
H' 00000024: CH1 Auto (0)/Manual (1) (36)
H' 00000025: CH1 SP mode (Local (0)/Remote (1)) (37)
Not used.
H' 00000040: The rest are the same as channel 1. (64)
···
0001 Event Input 2 Assignment The rest are the same as Event Input 1 Assignment.
Not used.
0010 Auxiliary Output 1 Assignment H' 00000000: Disabled (0)
H' 00000001: Temperature Controller error (1)
20 --- Common --- ●
Not used.
H' 00000010: Event input 1 (16)
H' 00000011: Event input 2 (17)
H' 00000012: Event input 3 (18)
H' 00000013: Event input 4 (19)
H' 00000014: Bus input 1 (20)
H' 00000015: Bus input 2 (21)
H' 00000016: Bus input 3 (22)
0011 Auxiliary Output 2 Assignment The rest are the same as Auxiliary Output 1 Assignment. 21
0012 Auxiliary Output 3 Assignment 22
0013 Auxiliary Output 4 Assignment 0
Not used.
0020 Bus Input 1 Assignment H' 00000000: Disabled (0)
H' 00000001: All channels Bank (bit0) (1)
H' 00000002: All channels Bank (bit1) (2)
H' 00000003: All channels Stop (0)/Run (1) (3)
H' 00000004: All channels Run (0)/Stop (1) (4)
H' 00000005: All channels Auto (0)/Manual (1) (5)
H' 00000006: All channels SP mode (Local (0)/Remote
(1)) (6)
0 --- Common ● ---
Not used.
H' 00000020: CH1 Bank (bit0) (32)
H' 00000021: CH1 Bank (bit1) (33)
H' 00000022: CH1 Stop (0)/Run (1) (34)
H' 00000023: CH1 Run (0)/Stop (1) (35)
H' 00000024: CH1 Auto (0)/Manual (1) (36)
H' 00000025: CH1 SP mode (Local (0)/Remote (1)) (37)
Not used.
H' 00000040: Channel 2: The same as channel 1. (64)
···
H' 00000060: Channel 3: The same as channel 1. (96) TC4 ---
···
H' 00000080: Channel 4: The same as channel 1. (128)
···
0021 Bus Input 2 Assignment The rest are the same as Bus Input 1 Assignment.
0022 Bus Input 3 Assignment
