208
Parameter List Appendix
F2 (B2)
Enabled
after
resetting.
Not used.
0030 Bus Output 1 Assignment H' 00000000: Disabled (0)
H' 00000001: Temperature Controller error (1)
TC: 4
HFU: 0
--- Common ●●
H' 00000002: All channels All alarm OR (2)
H' 00000003: All channels All alarm AND (3)
H' 00000004: All channels Alarm 1 OR (4)
H' 00000005: All channels Alarm 2 OR (5)
H' 00000006: All channels Alarm 3 OR (6)
H' 00000007: All channels Alarm 1 AND (7)
H' 00000008: All channels Alarm 2 AND (8)
H' 00000009: All channels Alarm 3 AND (9)
H' 0000000A: All channels Input error OR (10)
H' 0000000B: All channels RSP Input error OR (11)
---
Not used.
H' 0000000D: All channels HB (Heater Burnout) alarm
OR (13)
H' 0000000E: All channels HS (Heater Short) alarm OR
(14)
H' 0000000F: All channels OC (Heater Overcurrent)
alarm OR (15)
H' 00000010: Event input 1 (16) TC2
H' 00000011: Event input 2 (17)
H' 00000012: Event input 3 (18) ---
H' 00000013: Event input 4 (19)
H' 00000014: Bus input 1 (20)
H' 00000015: Bus input 2 (21)
H' 00000016: Bus input 3 (22)
Not used.
H' 00000020: CH1 Alarm 1 (32)
H' 00000021: CH1 Alarm 2 (33)
H' 00000022: CH1 Alarm 3 (34)
H' 00000023: CH1 All alarm OR (35)
H' 00000024: CH1 All alarm AND (36)
H' 00000025: CH1 Input error (37)
H' 00000026: CH1 RSP Input error (38)
---
Not used.
H' 00000028: CH1 HB (Heater Burnout) alarm (40)
H' 00000029: CH1 HS (Heater Short) alarm (41)
H' 0000002A: CH1 OC (Heater Overcurrent) alarm (42)
Not used.
H' 00000032: CH1 Bank (bit0) (50)
H' 00000033: CH1 Bank (bit1) (51)
H' 00000034: CH1 Stop (0)/Run (1) (52)
H' 00000035: CH1 Run (0)/Stop (1) (53)
H' 00000036: CH1 Auto (0)/Manual (1) (54)
H' 00000037: CH1 SP mode (Local (0)/Remote (1)) (55)
Not used.
H' 00000040: Channel 2: The same as channel 1. (64)
···
0030 H' 00000060: Channel 3: The same as channel 1. (96) TC4
···
H' 00000080: Channel 4: The same as channel 1. (128)
···
0031 Bus Output 2 Assignment The rest are the same as Bus Output 1 Assignment. TC: 5
HFU: 0
0032 Bus Output 3 Assignment TC: 6
HFU: 0
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
