Omron EJ1 User Manual

211
Status Lists Appendix
Configuration Error A Status
Configuration Error B Status
Bit position Status Bit description Meaning
01
Bit 0 Undefined Expand Units No error Error A Unit that is not recognized is connected.
Bit 1 Not used.
Bit 2 Too Many Expand units No error Error More than 9 G3ZA Units are connected.
Bit 3 Expand Unit Failure No error Error There is an error in communications with the G3ZA.
Bit 4 Expand Unit Connec-
tion Fault
No error Error A communications response has not been received
from a G3ZA after it was registered in the configura-
tion.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 Expand Unit 1 Error No error Error There is an error in communications with the
G3ZA1.
Bit 1 Expand Unit 2 Error No error Error There is an error in communications with the
G3ZA2.
Bit 2 Expand Unit 3 Error No error Error There is an error in communications with the
G3ZA3.
Bit 3 Expand Unit 4 Error No error Error There is an error in communications with the
G3ZA4.
Bit 4 Expand Unit 5 Error No error Error There is an error in communications with the
G3ZA5.
Bit 5 Expand Unit 6 Error No error Error There is an error in communications with the
G3ZA6.
Bit 6 Expand Unit 7 Error No error Error There is an error in communications with the
G3ZA7.
Bit 7 Expand Unit 8 Error No error Error There is an error in communications with the
G3ZA8.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
C4/84 0002
C4/84 0003
