210
Status Lists Appendix
Device A Status
Device Error Status
Bit position Status Bit description Meaning
01
Bit 0 Device Error No error Error There is a memory error.
Refer to Device Error Status.
Bit 1 Configuration Error No error Error There is an error in the device configuration.
Refer to Configuration Error A Status, and Configu-
ration Error B Status.
Bit 2 Channel Error No error Error There is an error in one of the channels.
Refer to Error Channel A Status.
Bit 3 Not used.
Bit 4 Expand Communica-
tions Error
No error Error There is an error in communications with the con-
nected G3ZA.
Refer to Internal Communications Error Status.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 I/O Error No error Error There is an I/O error.
Refer to I/O Error Status.
Bit 11 Lower-level I/O Error No error Error There is an error in the connected G3ZA.
Refer to Basic Unit/Expand Unit Error Status.
Bit 12 I/O Alarm No error Error There is an I/O alarm.
Refer to I/O Alarm A Status and I/O Alarm B Status.
Bit 13 Lower-level I/O Alarm No error Error An alarm has occurred in the connected G3ZA.
Refer to Basic Unit/Expand Unit Alarm Status.
Bit 14 I/O Notification No error Error There is an I/O notification.
Refer to I/O Notification A Status.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 Not used.
Bit 1 Not used.
Bit 2 Not used.
Bit 3 Not used.
Bit 4 EEPROM Error No error Error There is a memory error.
Bit 5 Calibration Error No error Error There is a memory error.
Bit 6 Setting Value Error No error Error There is a memory error.
Bit 7 Not used.
Bit 8 Configured Registration
Data Error
No error Error There is a memory error.
Bit 9 Model Information Data
Error
No error Error There is a memory error.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Model Information Mis-
matching Error
No error Error There is a memory error.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
C4/84 0000
C4/84 0001
