215
Status Lists Appendix
Basic Unit/Expand Unit Error Status
Basic Unit/Expand Unit Alarm Status
Bit position Status Bit description Meaning
01
Bit 0 Expand Unit 1 Error No error Error
The G3ZA1 has generated a zero cross error.
Bit 1 Expand Unit 2 Error No error Error
The G3ZA2 has generated a zero cross error.
Bit 2 Expand Unit 3 Error No error Error
The G3ZA3 has generated a zero cross error.
Bit 3 Expand Unit 4 Error No error Error
The G3ZA4 has generated a zero cross error.
Bit 4 Expand Unit 5 Error No error Error
The G3ZA5 has generated a zero cross error.
Bit 5 Expand Unit 6 Error No error Error
The G3ZA6 has generated a zero cross error.
Bit 6 Expand Unit 7 Error No error Error
The G3ZA7 has generated a zero cross error.
Bit 7 Expand Unit 8 Error No error Error
The G3ZA8 has generated a zero cross error.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 Expand Unit 1 Alarm OFF ON
The G3ZA1 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 1 Expand Unit 2 Alarm OFF ON
The G3ZA2 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 2 Expand Unit 3 Alarm OFF ON
The G3ZA3 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 3 Expand Unit 4 Alarm OFF ON
The G3ZA4 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 4 Expand Unit 5 Alarm OFF ON
The G3ZA5 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 5 Expand Unit 6 Alarm OFF ON
The G3ZA6 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 6 Expand Unit 7 Alarm OFF ON
The G3ZA7 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 7 Expand Unit 8 Alarm OFF ON
The G3ZA8 has a heater burnout, overcurrent, or SSR
short circuit.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
C4/84 000F
C4/84 0010
