Omron EJ1 User Manual

216
Status Lists Appendix
Output Status
Device B Status
Bit position Status Bit description Meaning
01
Bit 0 Control Output 1 OFF ON The control output 1 status can be checked.
Bit 1 Control Output 2 OFF ON The control output 2 status can be checked.
Bit 2 Control Output 3 OFF ON The control output 3 status can be checked.
Bit 3 Control Output 4 OFF ON The control output 4 status can be checked.
Bit 4 Not used.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 Save RAM 1 No error Error Power was turned OFF while saving RAM1 and not
all data was registered.
Bit 1 Save RAM 2 No error Error Power was turned OFF while saving RAM2 and not
all data was registered.
Bit 2 Save Control Parame-
ters
No error Error Power was turned OFF during parameter registra-
tion after autotuning was completed, and not all
data was registered.
Bit 3 Registration of unit con-
figuration/Registration of
multiple reads
No error Error Power was turned OFF during Unit configuration
registration or composite read registration and not
all data was registered.
Bit 4 Not used.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Write Mode Backup RAM write Write mode can be confirmed.
Bit 9 EEPROM RAM =
EEPROM
RAM ≠
EEPROM
Can confirm whether or not the setting is registered
in EEPROM.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Configuration Regis-
tered
Not regis-
tered
Registered Configuration registration status can be confirmed.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
C4/84 0012
C4/84 0013
