217
Status Lists Appendix
Channel Status
Channel Alarm Status
Bit position Status Bit description Meaning
01
Bit 0 RUN/STOP Run Stop Run/Stop can be confirmed.
Bit 1 Auto/Manual Auto Manual Auto/Manual can be confirmed.
Bit 2 AT Execute/Cancel AT is
stopped
AT
execution in
progress
Can confirm AT Execute/Cancel.
Bit 3 SP Mode LSP RSP SP mode can be confirmed.
Bit 4 Not used.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Input Error No error Error An input error has occurred.
Bit 9 RSP Input Error No error Error An RSP input error has occurred.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 Alarm 1 OFF ON An alarm 1 error has occurred.
Bit 1 Alarm 2 OFF ON An alarm 2 error has occurred.
Bit 2 Alarm 3 OFF ON An alarm 3 error has occurred.
Bit 3 Not used.
Bit 4 Heater Overcurrent No error Error A heater overcurrent has occurred.
Bit 5 HB Alarm OFF ON An HB alarm has occurred.
Bit 6 HS Alarm OFF ON An HS alarm has occurred.
Bit 7 OC Alarm OFF ON An OC alarm has occurred.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Set Point Limiter Out of
Range
No error Error The set point is outside the set point limiter range.
Bit 13 Set Value Limiter
Reverse Operation
No error Error The upper and lower set point limits are reversed.
Bit 14 MV Limiter Reverse
Operation
No error Error The upper and lower MV limits are reversed.
Bit 15 Scaling Reverse
Operation
No error Error The upper and lower scaling limits are reversed.
C4/84 0101 (CH1)·0201 (CH2)·0301 (CH3)·0401 (CH4)
C4/84 0102 (CH1)·0202 (CH2)·0302 (CH3)·0402 (CH4)
