Omron EJ1 User Manual

214
Status Lists Appendix
I/O Notification A Status
Error Channel A Status
Bit position Status Bit description Meaning
01
Bit 0 CT1 Heater Current
Hold
Updated Hold The heater current monitor has not been updated
because the control output ON time is less than 100
ms.
Bit 1 Not used.
Bit 2 Not used.
Bit 3 Not used.
Bit 4 CT2 Heater Current
Hold
Updated Hold The heater current monitor has not been updated
because the control output ON time is less than
100 ms.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 CH1 No error Error Channel 1 has an error.
Bit 1 CH2 No error Error Channel 2 has an error.
Bit 2 CH3 No error Error Channel 3 has an error.
Bit 3 CH4 No error Error Channel 4 has an error.
Bit 4 Not used.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
C4/84 0009
C4/84 000B
