Status Lists Appendix
I/O Alarm A Status
I/O Alarm B Status
Bit position Status Bit description Meaning
01
Bit 0 CT1 Heater Overcurrent No error Error The heater current 1 value exceeds 110.0 A.
Bit 1 CT2 Heater Overcurrent No error Error The heater current 2 value exceeds 110.0 A.
Bit 2 Not used.
Bit 3 Not used.
Bit 4 Not used.
Bit 5 Not used.
Bit 6 Not used.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
Bit position Status Bit description Meaning
01
Bit 0 CT1 HB Alarm OFF ON An HB alarm has occurred for CT1 input.
Bit 1 CT1 HS Alarm OFF ON An HS alarm has occurred for CT1 input.
Bit 2 CT1 OC Alarm OFF ON An OC alarm has occurred for CT1 input.
Bit 3 Not used.
Bit 4 CT2 HB Alarm OFF ON An HB alarm has occurred for CT2 input.
Bit 5 CT2 HS Alarm OFF ON An HS alarm has occurred for CT2 input.
Bit 6 CT2 OC Alarm OFF ON An OC alarm has occurred for CT2 input.
Bit 7 Not used.
Bit 8 Not used.
Bit 9 Not used.
Bit 10 Not used.
Bit 11 Not used.
Bit 12 Not used.
Bit 13 Not used.
Bit 14 Not used.
Bit 15 Not used.
