31
Unit Configurati
on Examples
Section 2-4
Restrictions on
Connections and
Plac
ement
•
Alwa
ys
connect the
HFU on the
left side of
the TC4/T
C2 Units.
•
Do not
connect
an EDU d
irectly t
o an HFU. Alwa
ys
connect th
e EDU
to a
TC4/TC2.
EJ1
@
-TC4
or
EJ1
@
-TC2
EJ1
@
-HFU
EJ1
@
-TC4
or
EJ1
@
-TC2
EJ1
@
-HFU
Correct
Incorrect
EJ1
@
-HFU
EJ1
@
-TC4
or
EJ1
@
-TC2
EJ1
@
-HFU
Correct
Incorrect
EJ1
@
-EDU
EJ1
@
-EDU
51
