Introduction
F3SJ-A
User’s Manual
•Install the emitter and receiver so that their vertical direction should match.
•If the protective height is 600 mm or more, use intermediate mounting brackets of specified quantities
and locations according to the dimensions.
If the brackets described above are not used, ratings and performance cannot be not met.
 Cleaning
Do not use thinner, benzene, or acetone for cleaning, because they affect the product's resin parts and
paint on the case.
 Object detection
The F3SJ cannot detect transparent and/or translucent objects.

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
