Omron F3SJ Series - Mounting

132
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
The adjustment angle of F39-LJ3 is from -10deg to +10deg.
When performing side mounting without using intermediate brackets for side mounting, F39-LJ3 brackets cannot be
used in combination with standard brackets.
Side mounting (when not using intermediate brackets for side mounting)
)/-
(Unit: mm)
31
16
24
25
46
45
45
1
6-M5
F
B
42 42 42
2-dia. 5.5
53
42
13
C (Protective height)
B
F
Material: Zinc die-cast
