Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
 F39-LJ4 Top/bottom Mounting Bracket B
Dimensions A to C
A C + 109
BC + 66
C 4-digit number of the model name (protective height)
F39-LJ4
19
66
37
2
1
B
19(*1)
30
4-M5
26
A B
21.5
(21.5)
30
45
Backside mounting
Use standard
brackets
C (Protective height)
(Unit: mm)
*1 A mounting width of 18 to 20 can be
supported when mounting with M5 screws.
Material: Stainless steel
