Omron F3SJ Series User Manual

199
F3SJ-A
User’s Manual
Chapter7 Glossary
Appendix
E
T Teaching Function that configures a target beam as interrupted for following functional settings.
- Muting function
- Fixed blanking function
- Floating blanking function
- Warning Zone function
- Designated beam output function
Test input ON
information
The external indicator turns ON when the test input is ON. When the test input is ON, the F3SJ activates
the external diagnosis function.
U Upper beams Indicate beams on F3SJ’s terminal.
User level Mode that reads receiving light intensity and monitors F3SJ’s operating status such as disturbance light
measurement by the setting tool. Password is not required to transition to this mode.
W Warning zone
information
This information is output from the auxiliary output or the external indicator when the warning zone is
blocked. Note that the warning zone information must be assigned to an output destination.
Warning zone function When part of the detection zone is configured as a warning zone, the unblocked/blocked status of the
zone does not affect the safety output. Instead, the unblocked/blocked status can be output from the
auxiliary output, etc.
Term Definition

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
