4 Parameter List
4 - 4
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Changes
during
RUN
Unit
Page
d062
Frequency
Reference Source
Monitor
00: Digital Operator (F001)
01 to 15: Multi-step speed frequency 1 to
15
16: Jogging frequency
18: Modbus communication
19: Option
21: Volume
22: Pulse train frequency
23: Operation function output
24: DriveProgramming
25: Analog voltage input (O)
26: Analog current input (OI)
27: Analog Input (O) + (OI)
−
−
−
P. 7-14
d063
RUN Command
Source Monitor
1: Control circuit terminal block
2: Digital Operator
3: Modbus communication
4: Option
−
−
−
P. 7-14
d080
Fault Counter
0. to 65535.
−
−
time
P. 7-14
d081
Fault Monitor 1
(Latest)
Fault Factor
• Output frequency [Hz]
*1
• Output Current [A]
• Main circuit DC voltage [V]
• Total RUN Time [h]
• Total Power ON Time [h]
−
−
−
P. 7-15
d082
Fault Monitor 2
d083
Fault Monitor 3
d084
Fault Monitor 4
d085
Fault Monitor 5
d086
Fault Monitor 6
d090
Warning Monitor
Warning code
−
−
−
P. 7-15
d102
DC Voltage Monitor
0.0 to 1000.0
−
−
V
P. 7-15
d103
Regenerative Brak-
ing Load Rate Moni-
tor
0.0 to 100.0
−
−
%
P. 7-16
d104
Electronic Thermal
Load Rate Monitor
0.0 to 100.0
−
−
%
P. 7-16
d130
Analog Voltage Input
O Monitor
0 to 1023 (1023= Equivalent to A/D con-
verter output of 10.9 V)
−
−
−
P. 7-16
d131
Analog Current Input
OI Monitor
0 to 1023 (1023= Equivalent to A/D con-
verter output of 23.3 mA)
−
−
−
P. 7-16
d133
Pulse Train Input EA
Monitor
0.00 to 100.00
−
−
%
P. 7-17
d153
PID Deviation
−9999.00 to 9999.00
*2
−
−
%
P. 7-17
d155
PID Output Monitor
−100.00 to 100.00
−
−
%
P. 7-17
*1. When the frequency is displayed, in high-frequency mode, the operator display resolution becomes 0.1
(equivalent to the 3G3MX2-E Series Inverter).
*2. The digit shift display mode can be used.
