4 Parameter List
4 - 25
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Multi-function
input terminals
C011
Multi-function Input 1
Operation Selection
00: NO (NO contact)
01: NC (NC contact)
00
Enabled
−
P. 5-47
C012
Multi-function Input 2
Operation Selection
00
Enabled
C013
Multi-function Input 3
Operation Selection
00
Enabled
C014
Multi-function Input 4
Operation Selection
00
Enabled
C015
Multi-function Input 5
Operation Selection
00
Enabled
C016
Multi-function Input 6
Operation Selection
00
Enabled
C017
Multi-function Input 7
Operation Selection
00
Enabled
Multi-function
output
terminals
C021
Multi-function Output
11 Selection
00: RUN (Signal during RUN)
01: FA1 (Constant speed arrival signal)
02: FA2 (Set frequency exceeded signal)
03: OL (Overload warning)
04: OD (Excessive PID deviation)
05: AL (Alarm signal)
06: FA3 (Set-frequency only signal)
07: OTQ (Overtorque/Undertorque signal)
09: UV (Signal during undervoltage)
10: TRQ (Torque limit)
11: RNT (RUN time over)
12: ONT (Power ON time over)
13: THM (Electronic thermal warning)
19: BRK (Brake release)
20: BER (Brake error)
21: ZS (0-Hz detection signal)
22: DSE (Excessive speed deviation)
23: POK (Position ready)
24: FA4 (Set frequency exceeded signal 2)
25: FA5 (Set-frequency only signal 2)
26: OL2 (Overload warning 2)
27: ODc (Analog O disconnection detection)
28: OIDc (Analog OI disconnection detection)
31: FBV (PID feedback comparison signal)
32: NDc (Communications disconnection
detection)
33: LOG1 (Logic operation output 1)
34: LOG2 (Logic operation output 2)
35: LOG3 (Logic operation output 3)
39: WAC (Capacitor life warning signal)
40: WAF (Cooling fan life warning signal)
41: FR (Starting contact signal)
42: OHF (Cooling fin overheat warning)
43: LOC (Low current signal)
44: MO1 (General-purpose output 1)
45: MO2 (General-purpose output 2)
46: MO3 (General-purpose output 3)
50: IRDY (Operation ready)
51: FWR (Forward run signal)
52: RVR (Reverse run signal)
53: MJA (Fatal fault signal)
54: WCO (Window comparator O)
55: WCOI (Window comparator OI)
58: FREF (Frequency reference source)
59: REF (RUN command source)
60: SETM (Motor 2 selection)
62: EDM (Safety device monitor)
*1
63: OPO (Option)
255: no (No allocation)
00
(RUN)
Enabled
C022
Multi-function Output
12 Selection
01
(FA1)
Enabled
−
P. 5-54
P. 7-20
C026
Multi-function Relay
Output (AL1, AL2)
Function Selection
05
(AL)
Enabled
*1. When the EDM function selector switch is ON, C021 is forcibly allocated to 62 (EDM). You cannot set 62 (EDM) manu-
ally. If you turn ON and then OFF the EDM function selector switch, C021 is set to 255 (no: No allocation).
4
4-3 Extended Function Mode
4-3-3 Group C: Multi-function Terminal Function Parameters

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
