Omron MX2 Series User Manual

4 Parameter List
4 - 26
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Analog
monitor
C027
EO Selection
00: Output frequency
01: Output current
02: Output torque (Only in the sensor-
less vector control)
03: Digital output frequency
04: Output voltage
05: Input power
06: Electronic thermal load rate
07: LAD frequency
08: Digital current monitor
10: Cooling fin temperature
12: DriveProgramming (YA(0))
15: Pulse train input monitor
16: Option (No applicable Option)
07
Enabled
−
P. 7-27
C028
AM Selection
00: Output frequency
01: Output current
02: Output torque (Only in the sensor-
less vector control)
04: Output voltage
05: Input power
06: Electronic thermal load rate
07: LAD frequency
10: Cooling fin temperature
11: Output torque (signed) (Only in the
sensorless vector control)
13: DriveProgramming (YA(1))
16: Option (No applicable Option)
07
Enabled
−
P. 7-29
C030
Digital Current Moni-
tor Reference Value
0.20  Rated current to 2.00  Rated cur-
rent
(Current value at digital current monitor
output 1440 Hz)
Rated
current
Enabled
A
P. 7-28
Multi-function
output
terminals
C031
Multi-function Output
11 Operation Selec-
tion
00: NO (NO contact)
01: NC (NC contact)
00
Enabled
−
P. 5-54
C032
Multi-function Output
12 Operation Selec-
tion
00
Enabled
C036
Multi-function Relay
Output (AL1, AL2)
Operation Selection
01
Enabled

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
