5 Basic Settings
5 - 4
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
No.
Display condition
Parameters displayed when condition is met
7
To display parameters
when 2nd Control Method
is set to V/f control (con-
stant torque or reduced
torque)
C001 to C007 = 08 and A244 =
00 or 01
A241 to A243, A246, A247
8
To display parameters
when DC injection braking
is active
A051 = 00 or 01, or C001 to
C007 = 07
A052 to A059
9
To display parameters
when PID function is
enabled
A071 = 01 or 02
d004, A072 to A079, A156, A157, C044, C052, C053
10
To display parameters
when the co-inverter com-
munication is enabled
C096 = 01 or 02
C098 to C100, P140 to P155
11
To display parameters
when curve accelera-
tion/deceleration function is
enabled
A097, A098 = 01 to 04
A131, A132, A150 to A153
12
To display parameters
when deceleration stop on
power interruption function
is enabled
b050 = 01 to 03
b051 to b054
13
To display parameters
when brake control func-
tion is enabled
b120 = 01
b121 to b127
14
To display parameters
when overvoltage suppres-
sion function during decel-
eration is enabled
b130 = 01 or 02
b131 to b134
15
To display parameters
when simple position con-
trol is enabled
P003 = 01
d008, P004, P011, P012, P014 to P017, P026, P027,
P060 to P073, P075, P077, P080 to P083, H050, H051
Any parameters set for U001 to U032 and the parameters F001, b037, b190, and b191 will be dis-
played.
• Displays only the changed parameters from the factory default settings.
• All monitor display parameters (d***), F001, b037, b190, and b191 will be always displayed.
Only monitor display parameters (d***), b037, b190, and b191 will be displayed.
User Setting (b037 = 02)
Data Comparison Display (b037 = 03)
Monitor Display Only (b037 = 05)

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
