6 Vector Control and Applied Functions
6 - 57
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
The following parameter selection functions are not available and therefore not displayed on the Digital
Operator.
Parameter No.
Function name
Unavailable selection functions
b001
Power Interruption/Undervoltage
Restart Selection
04:
Frequency pull-in restart
b008
Overvoltage/Overcurrent Restart
Selection
04:
Frequency pull-in restart
b088
Free-run Stop Selection
02:
Frequency pull-in restart
C001
Multi-function Input 1 Selection
06:
08:
14:
40:
41:
42:
44:
46:
47:
52:
66:
67:
68:
69:
70:
73:
85:
91:
JG (Jogging)
SET (2nd control)
CS (Commercial switching)
TL (Torque limit enabled)
TRQ1 (Torque limit switching 1)
TRQ2 (Torque limit switching 2)
BOK (Brake confirmation)
LAC (LAD cancel)
PCLR (Current position clear)
ATR (Torque reference input permission)
CP1 (Position command selection 1)
CP2 (Position command selection 2)
CP3 (Position command selection 3)
ORL (Origin search limit signal)
ORG (Origin search start signal)
SPD (Speed/Position switching)
EB (Rotation direction detection)
PSET (Preset current position)
C002
Multi-function Input 2 Selection
C003
Multi-function Input 3 Selection
C004
Multi-function Input 4 Selection
C005
Multi-function Input 5 Selection
C006
Multi-function Input 6 Selection
C007
Multi-function Input 7 Selection
C021
Multi-function Output 11 Selection
07:
10:
OTQ (Overtorque/Undertorque signal)
TRQ (Torque limit)
19:
BRK (Brake release)
C022
Multi-function Output 12 Selection
20:
BER (Brake error)
22:
DSE (Excessive speed deviation)
C026
Multi-function Relay Output (AL1,
AL2) Function Selection
23:
60:
POK (Position ready)
SETM (Motor 2 selection)
C027
EO Selection
02:
Output torque (Only in the sensorless vector control)
C028
AM Selection
02:
11:
Output torque (Only in the sensorless vector control)
Output torque (signed) (Only in the sensorless vec-
tor control)
C103
Reset Restart Selection
02:
Frequency pull-in restart
H001
Auto-tuning Selection
02:
Enabled (Motor rotation)
P003
Pulse Train Input EA Selection
01:
Frequency setting (including PID)
Unavailable Selection Functions
6
6-8 PM Motor Mode
6-8-2 Functional Limitations in PM Motor Mode

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
