7 Other Functions
7 - 19
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Data
Description
Reference item
Reference
page
23
PID: PID disabled
PID Function
P. 7-44
24
PIDC: PID integral reset
27
UP:
Remote
operation
accelerated
28
DWN:
Remote
operation
decelerated
Remote Operation Function
P. 7-40
29
UDC: Remote operation data clear
31
OPE: Forced operator function
Forced Operator Function
P. 7-55
32
SF1: Multi-step speed setting bit 1
33
SF2: Multi-step speed setting bit 2
34
SF3: Multi-step speed setting bit 3
35
SF4: Multi-step speed setting bit 4
Multi-step Speed Operation Function
P. 5-48
36
SF5: Multi-step speed setting bit 5
37
SF6: Multi-step speed setting bit 6
38
SF7: Multi-step speed setting bit 7
39
OLR: Overload limit switching
Overload Limit/Overload Warning
P. 7-78
40
TL: Torque limit enabled
41
TRQ1: Torque limit switching 1
Torque Limit Function Settings
P. 6-12
42
TRQ2: Torque limit switching 2
44
BOK: Brake confirmation
Brake Control Function Settings
P. 6-25
46
LAC: LAD cancel
Acceleration/Deceleration
Time
Settings
P. 5-32
47
PCLR: Current position clear
Simple Position Control Function
P. 6-28
50
ADD: Set frequency A145 addition
Frequency Addition Function
P. 7-39
51
F-TM: Forced terminal block
Forced Terminal Block Function
P. 7-55
52
ATR:
Torque
reference
input
permission
Torque Control
P. 6-16
C001 to
53
KHC: Integrated power clear
Integrated Power Monitor
P. 7-9
56
MI1: General-purpose input 1
C007
DriveProgramming Function
57
MI2: General-purpose input 2
58
MI3: General-purpose input 3
59
MI4: General-purpose input 4
60
MI5: General-purpose input 5
61
MI6: General-purpose input 6
62
MI7: General-purpose input 7
65
AHD: Analog command held
Analog Command Hold Function
P. 7-24
66
CP1: Position command selection 1
Simple Position Control Mode
P. 6-28
67
CP2: Position command selection 2
68
CP3: Position command selection 3
69
ORL: Origin search limit signal
70
ORG: Origin search startup signal
73
SPD: Speed/Position switching
81
485: Start co-inverter communica-
tion
Co-inverter Communication
P. 8-31
82
PRG: DriveProgramming start
DriveProgramming
83
HLD: Retain output frequency
Acceleration/Deceleration
Stop
Function
P. 7-37
84
ROK: Permission of RUN command
Permission of RUN Command
P. 7-38
85
EB: Rotation direction detection
Simple Position Control Function, V/f
Control with Speed Feedback (Can
be set for C005 only)
P. 6-28
86
DISP: Display fixed
Display Fixed
P. 7-57
91
PSET: Preset position
Current Position Preset
P. 6-40
255
no: No allocation
7
7-2 Multi-function Input/Output Functions
7-2-1 Multi-function Input Selection
