7 Other Functions
7 - 21
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Data
Description
Reference item
Reference
page
44
MO1: General-purpose output 1
DriveProgramming Function
−
45
MO2: General-purpose output 2
46
MO3: General-purpose output 3
50
IRDY: Operation ready
Operation Ready
P. 5-58
51
FWR: Forward run signal
Forward run signal
P. 5-58
52
RVR: Reverse run signal
Reverse run signal
P. 5-58
53
MJA: Fatal fault signal
Fatal Fault Signal
P. 7-89
54
WCO: Window comparator O
Window Comparator
P. 7-90
55
WCOI: Window comparator OI
58
FREF: Frequency command source
Frequency Reference Selection Status Signal
P. 7-91
59
REF: RUN command operator
RUN Command Status Signal
P. 7-91
60
SETM: Motor 2 selection
2nd Control Selection Signal
P. 7-92
62
EDM: Safety device monitor
Safety Function (Set via EDM function selec-
tor switch)
P. 7-99
63
OPO: Option
Do not set
−
255
no: No allocation
−
−
7
7-2 Multi-function Input/Output Functions
7-2-2 Multi-function Output Selection
