Parameter
No.
Setting item
Function name
Data
Default
data
Unit
00: Terminal O
P033
Torque Reference
Input Selection
10 V = 200%
01: Terminal OI
00
−
Torque control
20 mA = 200%
C001 to
C007
Multi-function Input 1
to 7 Selection
52: ATR
(Torque reference input
permission)
−
−
*1. This switches the frequency reference among the volume, current, and voltage based on the O/OI Selection
(A005) setting and the status of the multi-function input terminal allocated to 16 (AT: Analog input switching).
Here, volume represents the volume control (VR) on the optional Digital Operator (Model: 3G3AX-OP01).
*2. Setting the PID Selection (A071) to Enabled causes the analog input selection setting in A076 to be allocated
to the PID feedback function. When the 1st Frequency Reference Selection (A001) is set to 01 (Control circuit
terminal block), the analog input setting other than that selected in A076 is used as the target frequency refer-
ence. In this case, the setting in A005 and the function allocated to the terminal AT (Analog input switching)
are disabled.
*3. In A079, you can set a target value, or have a setting that overlaps with the PID Feedback Selection value.
With an overlapping setting, the analog input is used for both the feedback and feedforward signals.
*4. This parameter can be set to 02 (Analog voltage input) only. The torque limit is 200% with an input of 10 V.
When the analog input is used as a frequency reference, switching between voltage (O) and current
(OI is performed) is performed as shown in the table below.
However, when none of the multi-function input terminals are set to 16 (AT: Analog input switching),
regardless of the A005 setting, the frequency reference value is the sum of the analog voltage input O
and analog current input OI values.
Parameter
No.
Function
name
Data
Default
data
Unit
A005
O/OI
Selection
00: Switches between current and voltage based on ter-
minal AT (Analog input switching) status.
Terminal AT (Analog input switching) ON: Current
Terminal AT (Analog input switching) OFF: Voltage
02: Enabled only when 3G3AX-OP01 is used.
Switches between voltage and VR based on terminal
AT (Analog input switching) status.
Terminal AT (Analog input switching) ON: VR
Terminal AT (Analog input switching) OFF: Voltage
03: Enabled only when 3G3AX-OP01 is used.
Switches between current and VR based on terminal
AT (Analog input switching) status.
Terminal AT (Analog input switching) ON: VR
Terminal AT (Analog input switching) OFF: Current
00
−
C001 to
C007
Multi-function
Input 1 to 7
Selection
16: AT (Analog input switching)
−
−
Note For details on frequency reference settings, refer to 5-5 Frequency Reference Settings on page 5-23.
7
7-3 Analog I/O Settings
7-3-1 Analog Input (O, FI)

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
