Omron MX2 Series User Manual

8 Communications Functions
8 - 48
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parame-
ter No.
R/W
Monitor or setting data
Data
resolution
Page
101E hex
101D hex
Program Counter
(DriveProgramming)
d023
R
1 to 1024
1
P. 7-11
1101F hex
1101E hex
Program Number
Monitor
(DriveProgramming)
d024
R
0 to 9999
1
P. 7-11
1020 to
1025 hex
−
Reserved
−
−
−
−
−
1026 hex
1025 hex
DC Voltage Monitor
d102
R
0 to 10000
0.1 [V]
P. 7-15
1027 hex
1026 hex
Regenerative Braking
Load Rate Monitor
d103
R
0 to 1000
0.1 [%]
P. 7-16
1028 hex
1027 hex
Electronic Thermal
Load Rate Monitor
d104
R
0 to 1000
0.1 [%]
P. 7-16
1029 to
102D hex
−
Reserved
−
−
−
−
−
102E hex
102D hex
User Monitor 0
(DriveProgramming)
d025
(HIGH)
R
Displays DriveProgramming exe-
cution result
−2147483648 to 2147483647
1
P. 7-12
102F hex
102E hex
d025
(LOW)
1030 hex
1029 hex
User Monitor 1
(DriveProgramming)
d026
(HIGH)
R
Displays DriveProgramming exe-
cution result
−2147483648 to 2147483647
1
1031 hex
1030 hex
d026
(LOW)
1032 hex
1031 hex
User Monitor 2
(DriveProgramming)
d027
(HIGH)
R
Displays DriveProgramming exe-
cution result
−2147483648 to 2147483647
1
1033 hex
1032 hex
d027
(LOW)
1034 hex
−
Reserved
−
−
−
−
−
1035 hex
1036 hex
1035 hex
Position Command
Monitor
d029
(HIGH)
R
−268435455 to 268435455
1
P. 7-12
1037 hex
1036 hex
d029
(LOW)
R
1038 hex
1037 hex
Current Position
Monitor
d030
(HIGH)
R
−268435455 to 268435455
1
P. 7-12
1039 hex
1038 hex
d030
(LOW)
R
103A to
1056 hex
−
Reserved
−
−
−
−
−
1057 hex
1056 hex
Inverter Mode Monitor
d060
R
0: I-C (IM motor heavy load)
1: I-V (IM motor light load)
2: H-I (IM motor high fre-
quency)
3: P (PM motor mode)
−
P. 7-13
1058 hex
−
Not used
−
−
Not accessible
−
−
