8 Communications Functions
8 - 80
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
1492 hex
1491 hex
Logic Output Signal
1 Selection 1
C142
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
P. 7-85
1493 hex
1492 hex
Logic Output Signal
1 Selection 2
C143
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
1494 hex
1493 hex
Logic Output Signal
1 Operator Selection
C144
R/W
00: AND
01: OR
02: XOR
−
1495 hex
1494 hex
Logic Output Signal
2 Selection 1
C145
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
1496 hex
1495 hex
Logic Output Signal
2 Selection 2
C146
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
1497 hex
1496 hex
Logic Output Signal
2 Operator Selection
C147
R/W
00: AND
01: OR
02: XOR
−
1498 hex
1497 hex
Logic Output Signal
3 Selection 1
C148
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
1499 hex
1498 hex
Logic Output Signal
3 Selection 2
C149
R/W
Same as C021 (Except
33 (LOG1) to 35 (LOG3),
63 (OPO), and 255 (no))
−
149A hex
1499 hex
Logic Output Signal
3 Operator Selection
C150
R/W
00: AND
01: OR
02: XOR
−
149B to
14A3 hex
−
Reserved
−
−
−
−
−
14A4 hex
14A3 hex
Multi-function Input
1 Response Time
C160
R/W
0 to 200
2 [ms]
P. 5-47
14A5 hex
14A4 hex
Multi-function Input
2 Response Time
C161
R/W
0 to 200
2 [ms]
14A6 hex
14A5 hex
Multi-function Input
3 Response Time
C162
R/W
0 to 200
2 [ms]
14A7 hex
14A6 hex
Multi-function Input
4 Response Time
C163
R/W
0 to 200
2 [ms]
14A8 hex
14A7 hex
Multi-function Input
5 Response Time
C164
R/W
0 to 200
2 [ms]
14A9 hex
14A8 hex
Multi-function Input
6 Response Time
C165
R/W
0 to 200
2 [ms]
14AA hex
14A9 hex
Multi-function Input
7 Response Time
C166
R/W
0 to 200
2 [ms]
14AB to
14AC hex
−
Reserved
−
−
−
−
−
14AD hex
14AC hex
Multi-step
Speed/Position
Determination Time
C169
R/W
0 to 200
10 [ms]
P. 6-45
14AE to
1500 hex
−
Not used
−
−
Not accessible
−
−
