Omron MX2 Series User Manual

8 Communications Functions
8 - 88
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
165D hex
165C hex
Position Store
Selection at Power
Off
P081
R/W
00: Not store
01: Store
−
P. 6-44
165E hex
165D hex
Position Data at
Power Off
P082
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
165F hex
165E hex
P082
(LOW)
1660 hex
165F hex
Preset Position Data
P083
(HIGH)
R/W
Position range setting
(reverse side) to posi-
tion range setting (for-
ward side)
1
[pulse]
P. 6-43
1661 hex
1660 hex
P083
(LOW)
1662 to
1665 hex
−
Reserved
−
−
−
−
−
1666 hex
1665 hex
DriveProgramming
User Parameter U00
P100
R/W
0 to 65535
1
P. 7-105
1667 hex
1666 hex
DriveProgramming
User Parameter U01
P101
R/W
0 to 65535
1
1668 hex
1667 hex
DriveProgramming
User Parameter U02
P102
R/W
0 to 65535
1
1669 hex
1668 hex
DriveProgramming
User Parameter U03
P103
R/W
0 to 65535
1
166A hex
1669 hex
DriveProgramming
User Parameter U04
P104
R/W
0 to 65535
1
166B hex
166A hex
DriveProgramming
User Parameter U05
P105
R/W
0 to 65535
1
166C hex
166B hex
DriveProgramming
User Parameter U06
P106
R/W
0 to 65535
1
166D hex
166C hex
DriveProgramming
User Parameter U07
P107
R/W
0 to 65535
1
166E hex
166D hex
DriveProgramming
User Parameter U08
P108
R/W
0 to 65535
1
166F hex
166E hex
DriveProgramming
User Parameter U09
P109
R/W
0 to 65535
1
1670 hex
166F hex
DriveProgramming
User Parameter U10
P110
R/W
0 to 65535
1
1671 hex
1670 hex
DriveProgramming
User Parameter U11
P111
R/W
0 to 65535
1
1672 hex
1671 hex
DriveProgramming
User Parameter U12
P112
R/W
0 to 65535
1
1673 hex
1672 hex
DriveProgramming
User Parameter U13
P113
R/W
0 to 65535
1
1674 hex
1673 hex
DriveProgramming
User Parameter U14
P114
R/W
0 to 65535
1
1675 hex
1674 hex
DriveProgramming
User Parameter U15
P115
R/W
0 to 65535
1
1676 hex
1675 hex
DriveProgramming
User Parameter U16
P116
R/W
0 to 65535
1
1677 hex
1676 hex
DriveProgramming
User Parameter U17
P117
R/W
0 to 65535
1
1678 hex
1677 hex
DriveProgramming
User Parameter U18
P118
R/W
0 to 65535
1
1679 hex
1678 hex
DriveProgramming
User Parameter U19
P119
R/W
0 to 65535
1

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
