Omron MX2 Series User Manual

8 Communications Functions
8 - 95
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
1E01 hex
1E00 hex
Coil data 1
*1
−
R
2
0
:
Coil No. 0010 hex
to
2
15
:
Coil No. 001F hex
−
−
1E02 hex
1E01 hex
Coil data 2
*1
−
R
2
0
:
Coil No. 0020 hex
to
2
15
:
Coil No. 002F hex
−
−
1E03 hex
1E02 hex
Coil data 3
*1
−
R
2
0
:
Coil No. 0030 hex
to
2
15
:
Coil No. 003F hex
−
−
1E04 hex
1E03 hex
Coil data 4
*1
−
R
2
0
:
Coil No. 0040 hex
to
2
15
:
Coil No. 004F hex
−
−
1E05 hex
1E04 hex
Coil data 5
*1
−
R
2
0
:
Coil No. 0050 hex
to
2
8
:
Coil No. 0058 hex
−
−
1E06 to
1E18 hex
−
Reserved
−
−
−
−
−
1E19 to
1F00 hex
−
Not used
−
−
Not accessible
−
−
1F01 hex
1F00 hex
Coil data 0
*1
−
R/W
2
1
:
Coil No. 0001 hex
to
2
15
:
Coil No. 000F hex
−
−
1F02 to
1F1D hex
−
Reserved
−
−
−
*2
−
−
1F1E to
2102 hex
−
Not used
−
−
Not accessible
−
−
*1. Each of these holding registers (coil data 0 to 5) comprises 16 registers. Because the co-inverter communica-
tion function does not support coils (only holding registers are supported), use these holding registers to ac-
cess coils, if necessary.
*2. Do not write data to the holding registers 1F02 to 1F1D hex.
8
8-9 Modbus Communication Data Lists
8-9-4 Group A/b/C/H/P Register List

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
