Appendices
A - 10
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Model No.
Screw size
Required
torque [Nm]
Wire range
3G3MX2-AB001-EV2, 3G3MX2-AB002-EV2,
3G3MX2-AB004-EV2
M3.5
1.0
AWG16 (1.3 mm
2
)
3G3MX2-AB007-EV2
M4
1.4
AWG12 (3.3 mm
2
)
3G3MX2-AB015-EV2, 3G3MX2-AB022-EV2
M4
1.4
AWG10 (5.3 mm
2
)
3G3MX2-A2001-EV2, 3G3MX2-A2002-EV2,
3G3MX2-A2004-EV2, 3G3MX2-A2007-EV2
M3.5
1.0
AWG16 (1.3 mm
2
)
3G3MX2-A2015-EV2
M4
1.4
AWG14 (2.1 mm
2
)
3G3MX2-A2022-EV2
M4
1.4
AWG12 (3.3 mm
2
)
3G3MX2-A2037-EV2
M4
1.4
AWG10 (5.3 mm
2
)
3G3MX2-A2055-EV2, 3G3MX2-A2075-EV2
M5
3.0
AWG6 (13 mm
2
)
3G3MX2-A2110-EV2
M6
3.9 to 5.1
AWG4 (21 mm
2
)
3G3MX2-A2150-EV2
M8
5.9 to 8.8
AWG2 (34 mm
2
)
3G3MX2-A4004-EV2, 3G3MX2-A4007-EV2,
3G3MX2-A4015-EV2
M4
1.4
AWG16 (1.3 mm
2
)
3G3MX2-A4022-EV2, 3G3MX2-A4030-EV2
M4
1.4
AWG14 (2.1 mm
2
)
3G3MX2-A4040-EV2
M4
1.4
AWG12 (3.3 mm
2
)
3G3MX2-A4055-EV2, 3G3MX2-A4075-EV2
M5
3.0
AWG10 (5.3 mm
2
)
3G3MX2-A4110-EV2, 3G3MX2-A4150-EV2
M6
3.9 to 5.1
AWG6 (13 mm
2
)
Terminal Symbols and Screw Size
