Opticon L-46X - Code ID, Length, and Scan Time Settings

Chapter-7
String Options
L-46X User's Manual
96
1st
Code ID
7.2.4
Code ID can be added by sending following command continue to the prefix / suffix setting command.
Item
Command
Description
Default
Code identification
$2
Code identification using OPTICON ID
$1
Code identification using AIM ID/ ISO 15424
There are two ways of adding Code ID as follows.
● OPTICON Code ID: (Refer appendix 9.1.1)
● AIM/ISO Code ID: (Refer appendix 9.1.2)
The code identifier is transmitted in ISO 15424 format. ]cm
• ] is ASCII value, decimal 93
• c is code character
• m is modifier character
Example) Add “<OPTICON Code ID>” to the all codes prefix.
Configuring with Command:
<Esc>RY$2<CR>
Code Length 7.2.5
For 1D codes the code length is transmitted as 2 digits, excluding prefix and suffix characters. For 2D
codes the code length is transmitted as 6 digits. It is also possible to send the length as 6 digits for
both 1D and 2D codes. These direct input characters count as 1 entry of the 4 permissible entries for a
prefix and suffix.
Code length can be added by sending following command continue to the prefix / suffix setting
command.
Item
Command
Description
Default
Code length value
$3
Code length (1D/2D: 2/6 digit)
$6
Code length (1D/2D: 6/6 digit)
Example: Set the prefix for all codes to <Code length (1D/2D: 2/6 digit)>:
Configuring with Command:
<ESC>RY$3<CR>
Scan Time 7.2.6
The scan time is the time from trigger until data output start.
Item
Command
Description
Default
Scan time value
[EDG
Scan time
