L-46X specifications overview is as follows.
Common Specification Overview 9.2.1
Item
Specification
Note
Control
Section
CPU
CPU：ARM Cortex-A7
Core: 800 MHz
LPDDR2 RAM
1G bits
DDRCLK: 400 MHz
Flash ROM
1G bits Flash Memory
Interf
ace
RS-232C
300 bps to 115200 bps
Default: 9600 bps
USB
Full Speed 12 Mbps ( HID/COM )
Indicator
LED
Upper panel and side bars 3 color LED
Buzzer
Loudness / tone adjustable
Vibrator
Vibration motor (default off)
Option
Optical Section
Scanning method
Monochrome CMOS area sensor
Frame rate: 100 fps
Scanning light source
1 warm white LED
Aiming light source
1 green LED
Single line
Effective pixels
0.30 million pixels
View angle
Horizontal : about 38.0°
Vertical : about 28.9°
Diagonal : about 46.4°
Supported 1D Symbologies
Symbologies
1D
UPC-A, UPC-E, UPC-E1, UPC-A Add-on, UPC-E Add-on, EAN-13,
EAN-8, EAN-13 Add-on/EAN-8 Add-on, JAN-8, JAN-13, Code 39,
Codabar, Industrial 2 of 5, Interleaved 2 of 5, Code 93, Code 128,
GS1-128, MSI/Plessey, Code 11, UK/Plessey, Telepen, S-Code,
Matrix 2 of 5
Postal
Korean Postal Authority code, Chinese Post Matrix 2 of 5, Japan
Postal, Intelligent Mail Barcode, POSTNET, PLANET, Netherlands KIX
Code, Australian Postal, UK Postal, 4-State Mailmark Barcode
Curvature
Radius ≥ 20 mm (12-digit UPC)
PCS 0.9
Barcode width
Possible to read: Code 39 with 100 mm width
and resolution 0.2 mm (DOF: 127 mm)
Motion tolerance
Possible to read: UPC 0.33 mm moving at
2.54 m/s (DOF: 107 mm)
Depth of
field (Typ.)
Code 39
Resolution (0.127)
12 – 85 mm
Resolution (0.254)
11 – 196 mm
Resolution (0.508)
28 – 392 mm
Code 128
Resolution (0.20)
9 – 150 mm
UPC
Resolution (0.33)
9 – 250mm
