Opticon L-46X - Code128

Chapter-6
Code Options
L-46X User's Manual
76
1st
Code128
6.3.6
Code128 is developed by Computer Identix Inc. in the USA in 1981.
Code128 is a symbol standardized as USS-CODE128. Because it can encode ASCII128 characters, it
is called Code128.
Code128 Overview
Following are the Code128 configuration.
Item
Overview
Character set
ASCII128 character
Function character (FNC1-4)
Code set selection character (A, B, C and Shift)
Start / Stop code
Hidden character
Start pattern 3 types (A,B and C), Stop pattern 1 type
Digits
Variable length
CD (check digit) check method
Modulus 103
Transfer data format
Data (variable length)
● Setting items
GS1 conversion
Disable / Enable GS1-128 GS1 conversion is configurable.
Refer to 6.2.1 for setting detail.
Concatenation of Code 128
When Code128 data’s leading is FNC2 character, concatenate or not can be set.
Reading the barcode that contains FNC2 character in leading of Code128 data, concatenate the data
by omitting the leading FNC2.
When reading the barcode that does not contains FNC2 character in leading of Code128, it
concatenates the data to the end of data that is buffering to the scanner, and send entire buffer.
The reading time is updated every time 1 label is read, but if the reading is not completed within the
reading time, the buffered data will be discarded.
The maximum number of character that can be concatenated at a time is 400 characters.
Following are the Code 128 optional setting.
Code
Item
Command
Description
Default
Code 128
GS1 conversion
OF
Disable GS1-128

JF
Enable GS1-128 only
OG
Enable GS1-128 if possible
Concatenation
MP
Disable concatenation

MO
Enable concatenation
