Opticon L-46X - Model Details and Configurations

Chapter-2
Before Using
L-46X User's Manual
5
1st
Model Details
2.1
The L-46X model is constructed by a combination of following.
Model
name
Focus
Vibrator
Housing
Interface
Cable
length
Optional
AC adapter
Optional
Stand
L-46X
None
or
UD
-V
or
None
-BLK
or
-WHT
-USB
None (20)
None
+STD
or
None
-15
-24
-28
-RS232C
None (20)
+PS
-24
-28
-RS232C(9P)
None (20)
None
Standard 2.1.1
The following specs are the standard products.
Standard
Description
L-46X-BLK-USB+STD
Black housing USB-HID 2.0 m cable with stand
L-46X-BLK-RS232C+PS+STD
Black housing RS-232C 2.0 m cable with AC adapter and stand
Note: Other combinations only as special order, please contact sales offices for this.
Model Description 2.1.2
● Focus
● Housing
Symbol
Description
Symbol
Description
None
Standard focus
-BLK
Black housing
UD
Ultra high resolution
-WHT
White housing
● Interface
● Cable Length
Symbol
Description
Symbol
Description
-USB
USB interface (default is USB-HID)
None
Cable length 2.0 m
-RS232C
RS-232C interface with power supply
(external AC adapter power supply spec)
-24
Cable length 2.4 m
-RS232C(9P)
RS-232C interface (power supply input connected to D-sub 9pin 9)
-28
Cable length 2.8 m
● Optional AC Adapter
● Optional Stand
Symbol
Description
Symbol
Description
None
AC adapter not included.
None
Dedicated Auto Trigger stand (STD-46) is not included.
+PS
AC adapter included
+STD
Dedicated Auto Trigger stand (STD-46) is included.
Note: Auto Trigger stand is also sold separately.
