Accessories
9.2.5
RS-232C model product is shipped with a dedicated AC adapter.
AC Plugs connectors can be changed for to match local requirements.
Weight Approx. 90 g (Excluding AC plug for exchanging.)
Mechanical Drawing as following drawing
<AC plug for exchanging>
<DC output side>
The polarity of the center of DC jack is plus (+).
1800±45
16.1±0.2
53.6±1
71.3±1
32.6±1
69.0±1
Unit: mm
1.7
4.0
Unit: mm
EIAJ Electrode classification 2
(EIAJ#2)
