Opticon L-46X - ECI Protocol Output

Chapter-6
Code Options
L-46X User's Manual
62
1st
ECI Protocol Output
6.2.6
This allows setting whether to output data relates to ECI (Extended Channel Interpretation) protocol
which is within 2D code (QR code, Data Matrix, Aztec Code, Maxi Code) data.
For the data that ECI protocol exists, ECI number is indicated with a 6-digits number following the
back-slack and 2 back-lash indicates back-slash.
To not to output ECI protocol, change the data career identifier to ID not using ECI protocol, delete the
6-digits number following the back-slash and replace the 2 back-slashes to 1 back-slash.
“Supported Code”
QR Code, Data Matrix, Aztec Code, Maxi Code
Output example)
Output:
]Q2\000001test\\test
Not output:
]Q1test\test
*Back-slash: ’\’
Setting command are as follows;
Item
Command
Description
Default
ECI protocol output
setting
[DLE
Not output ECI protocol

[DLF
Output ECI protocol
