Chapter-5
Interface
L-46X User's Manual
45
1st
RS-232C Basic Information
5.3.1
Following are the RS-232C interface basic information.
Item
Description
Default
Transfer speed
300 to 115200 bps
9600 bps
Data length
7/8 bits
8 bit
Parity bit
None/Even/Odd
None
Stop bit
1/2 bits
1 bit
Handshake
None, BUSY/READY, Modem, ACK/NAK
None
Other option
Flow control, Inter character delay
Baud Rate (Transfer Speed) 5.3.2
The baud rate is the rate at which bits are transmitted from the scanner to the host and vice versa.
Both the scanner and the host must be set to the same baud rate.
The following commands can be used to configure the baud rate. "Z2" (safe settings in non-volatile
memory) needs be used after these commands to activate and save the new configuration.
Item
Command
Description
Default
Remark
Baud rate
K1
300 bps
Enabled only with
“Z2”
K2
600 bps
K3
1200 bps
K4
2400 bps
K5
4800 bps
K6
9600 bps

K7
19200 bps
K8
38400 bps
K9
57600 bps
SZ
115200 bps
