Technical Specifications
9.2.2
Standard model reading characteristics
Item
Specification
Notes
Standard model
Minimum
Resolution
Code 39
GS1 DataBar
Composite Code
PDF417
QR Code
Data Matrix
: 0.1 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
OPTOELECTRONICS
test chart
Barcode
width
Possible to read:
Width 100 mm Code 39 Resolution 0.2 mm
(DOF: 127 mm)
Motion
tolerance
Possible to read:
UPC 100% moving at 2.54 m/s (DOC: 107 mm)
Standard model reading depth of field
Typical values of reading depth are as follows.
Resolution
Code
No. of
Digits or Character
Scanning Depth of field (mm)
(Typ)
Near
Far
0.127mm
Code 39
4 digits
12
85
0.254mm
Code 39
7 digits
11
196
0.508mm
Code 39
4 digits
28
392
0.20mm
Code 128
16 digits
9
150
0.33mm
UPC/EAN
12 digits
9
250
0.169mm
PDF417
58 character
8
105
0.254mm
PDF417
58 character
1
170
0.169mm
QR Code
44 character
19
70
0.381mm
QR Code
44 character
0
209
0.169mm
Data Matrix
40 character
21
75
0.254mm
Data Matrix
40 character
2
132
Note: The depth of field is a determined while using the OPTOELECTRONICS test chart PCS 0.9, without
specular reflection and at room temperature and room humidity.
