Standard model reading depth of field
Note: The depth of field is the typical value measured by tilting the test chart 15° from the optical axis.
0
50
100 150 200
250
300
350
0 50
50
25
25
75
100 125
[Unit: mm ]
100125
75
Code 39
Code 128
100%
EAN/UPC
PDF417
QR Code
Data Matrix
0.127mm
0.254mm
0.508mm
0.20mm
0.33mm
0.169mm
0.254mm
0.169mm
0.381mm
0.169mm
0.254mm
