Opticon L-46X - Illumination and Aiming Settings

Chapter-8
Read Options
L-46X User's Manual
104
1st
Illumination and Aiming
8.4
Warm white illumination for reading and Green LED aiming can be enabled or disabled.
Reading LED Illumination 8.4.1
Red LED illuminations enable / disable, illuminance method and brightness that are used for reading
can be set.
Following method is available for reading target that specular reflection is likely to occur.
● LED Illumination → Enable / Disable
When the illumination is disabled, the reading performance may be degraded.
However, when reading only the code displayed on the LCD screen, the reading performance may
improve.
● LED Illumination → Automatic switching
Floodlight ON and OFF are alternated. The illumination in which a code was read is memorized and
will be prioritized for subsequent reading.
This function is recommended when reading the target that specular reflection easily occurs.
● LED Illumination → Prevent specular reflection
Disable illumination only when specular reflection by LED illumination occur and reads.
Item
Command
Description
Default
LED illumination
mode
[D39
LED illumination → Enable
[D3A
LED illumination → Disable
[D3B
LED illumination → Automatic switching
[D3Q
LED illumination → Prevent specular reflection

LED illumination
brightness
[DDB
LED brightness → Standard

[DDC
LED brightness → Low
LED Aiming 8.4.2
Green LED floodlight used for aiming can be set to enable / disable. The brightness is also
configurable.
Item
Command
Description
Default
LED aiming
ON/OFF
[D3D
Enable LED aiming

[D3E
Disable LED aiming
LED aiming
brightness
[DDD
Brightness "High"

[DDE
Brightness "Standard"
[DDF
Brightness "Low"
