Opticon L-46X - Flow to Integrate

Chapter-1
Abstract
L-46X User's Manual
3
1st
Flow to Integrate
1.2
Following are the flow of integrating general scanner.
1. Examine and Select the Scanner
Examine technical introduction in
advance.
“Communication”
“Reading code”
● Before using
→ (Refer to 2)
● Product specification
overview
→ (Refer to 9.2)
2. Download Tools
According to the operation, download necessary tools from our website.
● Setting, Image acquisition, confirm
communication
→ “UniversalConfig”
UniversalConfig WIME
● USB-COM
→ “USB Driver”
● COM output  HID output conversion
→ “WIME”
3. Setting and Testing
In the actual enviroment, evaluate the optimum setting according to the operation and perform a
reading test.
● Configurations
→ (Refer to 3)
● Indicator
→ (Refer to 4)
● Interface
→ (Refer to 5)
● Code Options
→ (Refer to 6)
● String Options
→ (Refer to 7)
● Read Options
→ (Refer to 8)
4. Create Setting Menu
Create a 2D menu code suitable for operation.
● 2D menu code
→ (Refer to 3.1.2)
Integrate
